| Rated frequency | [Hz] | 50/60 |
| Rated voltage | [V] | 115/230 ;120/240 |
| Rated power | [kVA] | 7.5/7.8 |
| Max power | [kVA] | 8.0/8.3 |
| Rated current | [A] | 65.2/32.6 ;62.5/31.25 |
| Rated rotation speed | [RPM] | 3000/3600 |
| Pole No. |
| 2 |
| Phase number |
| 1 |
| Excitation mode |
| Self-excitation and constant voltage(with AVR) |
| Power factor | [COSΦ] | 1 |
| Insulation grade |
| F |
| Engine model No |
| 1100FE |
| Engine type |
| Single cylinder, in-lined, 4-stroke, air cooled, direct-injected |
| Bore x stroke | [mm] | 100x85 |
| Displacement | [cc] | 668 |
| Lubrication system |
| Pressure splashed |
| Lube oil brand |
| CD Grade Above or SAE 10W-30,SAE15W-40 |
| Lube oil capacity | [L] | 1.65 |
| Starting system |
| 12V Electric system |
| Fuel Type |
| 0#(summer),-10#(winter),-20#(chilliness ) diesel |
| Fuel Tank Capacity | [L] | 15 |
